Medical Waste Autoclave Hospital Waste Autoclave Sterilization Equipments

1 / 5

Medical Waste Autoclave Hospital Waste Autoclave Sterilization Equipments

Customization:	Available
Theory:	Autoclave
Type:	Pressure Steam Sterilization Equipments

Send Inquiry

Product Description

📋 Basic Information

Model NO.YG

CertificationCE

LCD DisplayWith LCD Display

MaterialStainless Steel

Guarantee TimeOne Year

Transport PackageWooden Case

OriginJiangsu

Production Capacity500 Sets/Year

HS Code84778000

🔬 Product Description

Medical Waste Autoclave Hospital Waste Autoclave Sterilization Equipments

Application

The machine is suitable for hospitals, pharmaceutical factories, scientific research institutes and other units to sterilize and dry cloths, dresses, metal instruments, culture medium and etc.

Structure & Features

Vessels is designed to the China National Standard-GB150 (Steel Pressure Vessel).
National Patent door interlock device.
National Patent sealing technology, closed inflatable seal ring with compressed air.
Control system is integrated by PLC and HMI, advanced function for recording, printing and storing.
The GMP validation port is provide for insertion of 16 temperature sensors for validation.
Independent temperature monitoring system.
The steam condenser is fitted in the exhaust/vacuum line to condense the steam before entering inside the vacuum pump.

Key Advantages

Touch-Screen Operation for user-friendly interface.
High Precision Pressure Controller.
Real-time Printing of Data and Curves.
National Patent Gate Lock Structure for enhanced safety.

Main Parameters and Utilities

Parameter	Value	Utility Item	Requirement
Design Pressure	0.245Mpa	Vacuum	-0.095Mpa
Working Pressure	0.22Mpa	Steam Pressure	0.4-0.6Mpa
Design Temperature	139℃	Tap Water Pressure	0.2-0.3Mpa
Working Temperature	134℃	Compressed Air Pressure	0.6-0.8Mpa

Size and Model Specifications

Model	Overall size (LWH)	Chamber size (LWH mm)	Steam (kg/cycle)	Power (Kw)	Water (Kg/cycle)	Weight (kg)
YG-0.1	82510801600	630400480	15	1	80	380
YG-0.25	89512201720	700600600	20	1.5	150	650
YG-0.36	119512201720	1000600600	25	1.5	150	760
YG-0.6	124513001880	1050680850	30	2	200	1100
YG-0.8	159513001880	1400680850	35	3	250	1300
YG-1.2	169513701960	15007501100	40	3	300	1900
YG-2.5	319513701960	30007501100	75	4.5	450	2800
YG-5	363618002200	340010001500	150	7.5	600	4500

Service Commitment

One year guarantee for the whole machine.
24 hours technical support.
Overseas engineering service available (Terms apply).
Lifelong maintenance instruction and best-priced spare parts.
Comprehensive training service for machine operators.

❓ Frequently Asked Questions

What types of medical waste can this autoclave sterilize?

The system is designed to sterilize cloths, dresses, metal instruments, and culture media, making it ideal for hospitals and laboratories.

Is the sterilization process recorded?

Yes, the control system is integrated with PLC and HMI, allowing for full recording, printing, and storage of sterilization data and curves.

What safety standards does the vessel meet?

All vessels are designed according to the China National Standard-GB150 for Steel Pressure Vessels and include a national patent door interlock device.

How is the seal maintained under pressure?

The unit utilizes national patent sealing technology featuring a closed inflatable seal ring with compressed air for maximum reliability.

What is the capacity range of these autoclaves?

We offer a wide range of sizes, from the YG-0.1 (630*400*480mm chamber) to the YG-5 (3400*1000*1500mm chamber) to suit different volume needs.

What kind of after-sales support is provided?

We offer a one-year guarantee, 24-hour technical support, and the option for overseas engineering services and operator training.

Product Detail

Medical Waste Autoclave Hospital Waste Autoclave Sterilization Equipments

Product Description
